1D simulation of the impact of direct water injection on a small SI engine performance and emissions
1
Department of Automotive Vehicles, Cracow Univertsity of Technology, Poland
Submission date: 2024-07-24
Final revision date: 2025-01-06
Acceptance date: 2025-01-13
Online publication date: 2025-02-14
Corresponding author
Marcin Noga
Department of Automotive Vehicles, Cracow Univertsity of Technology, Jana Pawla II 37, 31-864, Kraków, Poland
Department of Automotive Vehicles, Cracow Univertsity of Technology, Jana Pawla II 37, 31-864, Kraków, Poland
KEYWORDS
TOPICS
ABSTRACT
The paper contain results of 1D simualtion of the direct water injection for the four stroke single cylinder gasoline engine and shows comparison between cycles with and without water addition.Various water injection timing, as well as water to fuel ratios were considered, including injection during compression stroke and just after finishing the combustion. Results show that direct water injection in internal combustion engines has a minimal effect on overall performance parameters but improves emission levels, particularly reducing NOx emissions. Injection at 100 deg bTDC consistently shows the greatest reduction in NOx emissions across scenarios. However, late water injection during combustion increases HC emissions.
REFERENCES (17)
1.
Berni F, Breda S, Lugli M, Cantore G. A numerical investigation on the potentials of water injection to increase knock resistance and reduce fuel consumption in highly downsized GDI engines. Enrgy Proced. 2015;81:826-835. https://doi.org/10.1016/j.egyp....
2.
Cantani A, Viggiano A, Magi A. On direct injection of supercritical water into spark ignition engines as a strategy for heat recovery. Energy Technology, 2021;9:2100198. https://doi.org/10.1002/ente.2....
3.
Chen H, Wang C, Li X, Li Y, Zhang M, Peng Z et al. Quantitative analysis of water injection mass and timing effects on oxy-fuel combustion characteristics in a GDI engine fuelled with E10. Sustainability. 2023;15:10290. https://doi.org/10.3390/su1513....
4.
Falfari S, Bianchi G, Cazzoli G, Forte C, Negro S. Basics on water injection process for gasoline engines. Enrgy Proced. 2018;148:50-57. https://doi.org/10.1016/j.egyp....
5.
Ghazal OH, Borowski G. Use of water injection technique to improve the combustion efficiency of the spark-ignition engine: a model study. Journal of Ecological Engineering. 2019;20(2):226-233. https://doi.org/10.12911/22998....
6.
Li A, Zheng Z, Song Y. A simulation study of water injection position and pressure on the knock, combustion, and emissions of a direct injection gasoline engine. ACS Omega. 2021;6(28):18033-18053. https://doi.org/10.1021/acsome....
7.
Li X, Pei Y, Li D, Ajmal T, Rana KJ, Aitouche A et al. Effects of water injection strategies on oxy-fuel combustion characteristics of a dual-injection spark ignition engine. Energies. 2021;14:5287. https://doi.org/10.3390/en1417....
8.
Millo F, Gullino G, Rolando L. Methodological approach for 1D simulation of port water injection for knock mitigation in a turbocharged DISI engine. Energies. 2020;13:4297. https://doi.org/10.3390/en1317....
9.
Mishra S, Naik B, Mallikarjuna JM. Effect of direct water injection timing and quantity on combustion, performance, and emission characteristics of a homogeneous charge compression ignition engine − a CFD analysis. Appl Therm Eng. 2024;257B:124190. https://doi.org/10.1016/j.appl....
10.
Noga M, Moskal T. Evaluation of a pressure sensing glow plug in terms of its application possibility to control the combustion process of a hydrogen-powered spark-ignition engine. Combustion Engines. 2024;196(1):140-145. https://doi.org/10.19206/CE-17....
11.
Pryciński P, Pielecha P, Korzeb J, Pielecha, J, Kostrzewski M, Eliwa A. Air pollutant emissions of passenger cars in poland in terms of their environmental impact and type of energy consumption. Energies. 2024;17 :5357. https://doi.org/10.3390/en1721....
12.
Stępień Z. Vehicle related non exhaust particle emissions – Euro 7 requirements. Combustion Engines. 2024;199(4):15-29. https://doi.org/10.19206/CE-19....
13.
Voris AR, Lundberg M, Puzinauskas PV. Effect of ethanol content, water injection, and compression ratio on combustion and detailed emissions in an SI-GDI engine. Fuel. 2025;381A:133200. https://doi.org/10.1016/j.fuel....
14.
Zhang Z, Dai X, Zheng Z, Numerical simulation study on the effect of port water injector position on the gasoline direct injection engine. Processes. 2022;10:1909. https://doi.org/10.3390/pr1010....
15.
Zhuang Y, Lin Z, Zhai R, Huang Y, Nie B, Li Y. A study on the effect of spark plug micro-hole hydrogen injection on the spray and combustion processes of a gasoline engine with intake port water injection. Energy. 2025;315:134366. https://doi.org/10.1016/j.ener....
