ABSTRACT
The presented article outlines the changes that have occurred over the past quarter-century in the design and performance of micro class gas turbine engines. The primary goal is to determine the current stage of development in engine construction. To achieve this, a representative group of 83 micro-class engines was selected and categorized based on the date they were introduced into operation. The main performance criterion was the engine's thrust, as these types of engines are primarily used in short-lifespan unmanned aerial vehicles (UAVs). A rotational performance characteristic was identified for a family of engines grouped into three geometric series. These characteristics are presented in relative parameters, facilitating convenient implementation in UAV design. A new trend in fanjet engine construction was identified, where thrust generation is primarily driven by the mass flow of the working medium passing through the engine duct. This is observed in modern engines with thrust exceeding 20 daN. It was demonstrated that, while maintaining the same external dimensions, a contemporary engine can deliver three times the thrust of a similar engine designed at the beginning of the 21st century.
REFERENCES (18)
1.
Benini E, Giacometti S. Design, manufacturing and operation of a small turbojet engine for research purposes. Appl Energ. 2007;84(11):1102-1116. https://doi.org/10.1016/j.apen....

2.
BorgWarner. Performance turbocharger catalog. 2012 Edition BorgWarner Turbo Systems. 2012.

3.
Batt G. Jet flight Triumph. Radio Control Modeler. 1983;148-150.

4.
Czarnecki M, Olsen J. Combined methods in preliminary micro-scale gas turbine diffuser design: a practical approach. J Appl Fluid Mech. 2018;11:567-575. https://doi.org/10.29252/jafm.....

5.
De Giorgi MG, Campilongo S, Ficarella A. A diagnostics tool for aero-engines health monitoring using machine learning technique. Enrgy Proced. 2018;148:860-867. https://doi.org/10.1016/j.egyp....

6.
Ioannou E, Nucara P, Pullen K. Lightweight high-pressure ratio centrifugal compressor for vehicles: investigation of pipe diffuser designs by means of CFD. International Journal of Mechanical, Aerospace, Industrial, Mechatronic and Manufacturing Engineering. 2016;10(4):403-408.

7.
Kamps T. Model jet engines. Worcestershire, UK. Traplet Publications Limited. 2005.

8.
Kurzke J, Halliwell I. Component performance. Propulsion and power: an exploration of gas turbine performance modeling. Cham, Switzerland. Springer International Publishing; 2018. https://doi.org/10.1007/978-3-....

9.
Khalatov A, Nemchin O, Kuzmin A, Shkvar E, Kobzar S. Small-size jet-powered combat unmanned aircraft systems (in Ukrainian). Dniepro 2023. https://doi.org/10.23877/978-9....

10.
Kurzawska-Pietrowicz P. Comprehensive analysis of particle emissions from miniature turbojet engine. Combustion Engines. https://doi.org/10.19206/CE-19....

11.
Oppong F, van der Spuy S, von Backström T, Lacina Diaby. An overview of micro gas turbine engine performance investigation. R & D Journal of the South African Institution of Mechanical Engineering. 2015;31:35-41. https://doi.org/10.13140/RG.2.....

12.
Parish R, Wright J, Murphy M. Plans for the MW54 gas turbine. 2nd ed. Worcestershire. Wren Turbines Ltd. 2000.

13.
Schreckling K. Gas turbine engines for model aircraft. Worcestershire, UK. Traplet Publications Limited. 1995.

14.
Schreckling K. Home build turbines. Worcestershire, UK. Traplet Publications Limited. 2005.

15.
Schreckling K. Model turbo-prop engine for home construction. Worcestershire, UK. Traplet Publications Limited. 2005.

16.
Sehra AK, Shin J. Revolutionary propulsion systems for 21st century aviation. Washington 2003. NASA Technical Memorandum TM-2003-212615.

17.
Ułanowicz L, Szczepaniak P, Jastrzębski G. Reverse engineering modeling of jet turbine engine blade ring palisade geometry. Journal of Konbin. 2024;54(4):135-158. https://doi.org/10.5604/01.300....

18.
van Eck H, van der Spuy S. Upgrading the compressor stage of the CAT250TJ micro gas turbine engine. Aerotec Missili Spaz. 2025;104:91-104. https://doi.org/10.1007/s42496....
