ABSTRACT
The article presents the directions of development of drive systems in trucks. A database of vehicles and their technical data was developed. This data contains information about the drivetrain configuration. The external characteristics of the engines and the structure of the drivetrain were analyzed. It was found that the factors determining development are primarily economic and ecological aspects. It was noticed that, based on the configuration of the drive system, vehicles can be divided according to their purpose and type of transport. Vehicles intended for international transport are characterized by low gears and engines that achieve high torque at low engine speeds. Construction vehicles and vehicles intended for oversize transport are characterized by large gear ratios and torque amplification systems. The structure of electric vehicle drive systems is different from conventional vehicles. Gearboxes usually have two gears, drive axles may have integrated engines located next to the main gear or in the final drive position. The study also made it possible to outline the problem of the short range of such cars and the need for further work on increasing it.

REFERENCES (25)
1.
A semi-trailer with a drive as powerful as the tractor (Naczepa z napędem równie mocnym co ciągnik – in Polish). https://40ton.net/naczepa-z-na....

2.
Andrych-Zalewska M, Chłopek J, Merkisz J, Pielecha J. Investigations of exhaust emissions from a combustion engine under simulated actual operating conditions in real driving emissions test. Energies. 2021;14:1-20. https://doi.org/10.3390/en1404....

3.
Chojnowski J, Karczewski M. Analysis of the market structure of long-distance transport vehicles in the context of retrofitting diesel engines with modern dual-fuel systems. Combustion Engines. 2022;188(1):13-17. https://doi.org/10.19206/CE-14....

4.
DENS pilot demos for hydrozine generator. Fuel Cells Bulletin. 2021;2021(5) https://doi.org/10.1016/S1464-....

5.
Eckenfels T, Fischer N, Lehmann S, Neuberth U, Reitz D. Innovative hybrid transmissions with electric DNA. Schaeffler Kolloquium. Digital conference book 2022. https://www.schaeffler.com/rem....

6.
Electric refrigerator with an electric generator (Elektryczna chłodnia z elektrycznym agregatem – in Polish). Transport Technika Motoryzacyjna 2018;7.

7.
Karczewski M, Szamrej G, Chojnowski J. Experimental assessment of the impact of replacing diesel fuel with CNG on the concentration of harmful substances in exhaust gases in a dual fuel diesel engine. Energies. 2022;15:4563. https://doi.org/10.3390/en1513....

8.
Kozak M, Lijewski P, Fuc P. Exhaust emissions from a city bus fuelled by oxygenated diesel fuel. SAE Technical Paper 2020-01-2095. 2020. https://doi.org/10.4271/2020-0....

9.
Kozak M, Lijewski P, Waligórski M. Exhaust emissions from a hybrid city bus fuelled by conventional and oxygenated fuel. Energies. 2022;15(3):1123. https://doi.org/10.3390/en1503....

10.
Krone semi-trailer equipped with e-axle – up to 40% savings (Naczepa Krone wyposażona w e-oś – do 40% oszczędności – in Polish). https://trailertotaal.nl/nieuw....

11.
Longwic R, Tatarynow D, Kuszneruk M, Wozniak-Borawska G. Preliminary tests of a Diesel engine powered by diesel and hydrogen. Combustion Engines. 2023;195(4):35-39. https://doi.org/10.19206/CE-16....

12.
MAN Truck&Bus Polska has a successful anniversary year (MAN Truck&Bus Polska udany rok jubileuszu – in Polish). Transport Technika Motoryzacyjna. 2018;8.

13.
Merkisz J, Bajerlein M, Zieliński B. The impact of parameter modifications in the Diesel engine power system on the emissions of harmful compounds. Combustion Engines. 2020;180(1):36-40. https://doi:10.19206/CE-2020-1....

14.
Merkisz J, Kozak M, Molik P, Nijak D, Andrzejewski M, Nowak M et al. The analysis of the emission level from a heavy-duty truck in city traffic. Combustion Engines. 2012;150(3):80-88. https://doi.org/10.19206/CE-11....

15.
Quiros DC, Thiruvengadam A, Pradhan S, Besch M, Thiruvengadam P, Demirgok B et al. Real-world emissions from modern heavy-duty diesel, natural gas, and hybrid diesel trucks operating along major California Freight Corridors. Emiss Control Sci Technol. 2016;2:156-172. https://doi.org/10.1007/s40825....

16.
Refrigerator tests with a power-generating axle - up to 9 hours of pause without turning on the diesel (Testy chłodni z osią generującą prąd – nawet 9 godzin pauzy bez włączania diesla – in Polish). https://40ton.net/testy-chlodn....

17.
SAF-Holland E-axle Family from SAF. https://safholland.com/pl/en/d....

18.
Schaefler Technologies for hybrid and all-electric drive systems. https://www.schaeffler.pl/en/p....

19.
Schmitz Cargobull S.KOe koelt elektrisch. https://trailertotaal.nl/nieuw....

20.
Volvo FL electric truck. https://www.volvotrucks.pl/pl-....

21.

22.
ZF’s CeTrax lite electric drive for LCVs begins series production. https://www.greencarcongress.c....

23.
ZF Tansmision & E-Mobility Driveline Systems for Trucks & Vans. https://www.zf.com/public/org/....

24.
Ziółkowski A, Fuć, P, Jagielski A, Bednarek M. Analysis of emissions and fuel consumption in freight transport. Energies. 2022;15:4706. https://doi.org/10.3390/en1513....

25.
Ziółkowski A, Fuć P, Lijewski P, Rymaniak Ł, Daszkiewicz P, Kamińska M et al. Analysis of exhaust emission measurements in rural conditions from heavy-duty vehicle. Combustion Engines. 2020;182(3):54-58. https://doi.org/10.19206/CE-20....
